| M4x0.7 Hex Nut |
1004010703 |
GR 6 |
ISO 4032 |
| Across Flat |
6.78 / 7.00 |
| Across Corner |
7.66Min |
| Total Thicknes |
2.90 / 3.20 |
|
| M5x0.8 Hex Nut |
1005020804 |
GR 6 |
DIN 934 |
| Across Flat |
7.73 / 8.00 |
| Across Corner |
8.79 Min |
| Total Thicknes |
3.70 / 4.00 |
|
| M6x1.00 Hex Nut |
1006021005 |
GR 6 |
ISO 4032 |
| Across Flat |
9.73 / 10.00 |
| Across Corner |
11.02 Min |
| Total Thicknes |
4.90 / 5.20 |
|
| M8x1.25 Hex Nut |
1008041307 |
GR 8 |
ISO 4032 |
| Across Flat |
12.73 / 13.00 |
| Across Corner |
14.38 Min |
| Total Thicknes |
6.44 / 6.80 |
|
| M10x1.5 Hex Nut |
1010051608 |
GR 8 |
ISO 4032 |
| Across Flat |
15.73 / 16.00 |
| Across Corner |
17.77 Min |
| Total Thicknes |
8.04 / 8.40 |
|
| M12x1.75 Hex Nut |
1012061811 |
GR 8 |
ISO 4032 |
| Across Flat |
17.73 / 18.00 |
| Across Corner |
20.03 Min |
| Total Thicknes |
10.37 / 10.80 |
|
| M14x1.5 Hex Nut |
1014052113 |
GR 8 |
ISO 4032 |
| Across Flat |
20.67 / 21.00 |
| Across Corner |
23.36 Min |
| Total Thicknes |
12.10 / 12.80 |
|
| M16x1.5 Hex Nut |
1016052415 |
GR 8 |
ISO 4032 |
| Across Flat |
23.67 / 24.00 |
| Across Corner |
26.75 Min |
| Total Thicknes |
14.10 / 14.80 |
|
